Shri Krishna Pin Mill

Introduction

Shri Krishna Pin Mill is specially designed to deal efficiently and economically with a wide range of materials and can be easily adjusted to give the fineness required from a coarse granulation to finely ground powder.

Pin Mill Grinding is gradually done from the centre to the periphery of the Rotor, allowing heavy pieces of material to be reduced by stages to the fineness required. Constructional materials and operating components are manufactured out of the best applicable raw materials, so as to yield close particle size for a similar product.

in mill yields greater output in relation to the Electrical Energy consumed, since the material can be ground is fed automatically in the centre of the Rotor by the Feed Hooper provided with an automatic vibrating tray / rotor feeder & gear box for automatic feed.

Pin mill is subjected to rigid Final inspection and actual Grinding Tests at our Experimental Station before it is delivered to the Stores for dispatch. Grinding Tests with your materials can also be carried out without obligation, to testing the suitability of the pin mill for your satisfaction.

Industries Pin mill is used in
  • Dye stuff pigment and color
  • Chemical
  • Food Stuff
  • Spice
  • Bakery
  • Confectionary
  • Agro
  • Salt
  • Ayurveda
  • Pharmaceutical
  • Dehydrated Fruit fit and Vegetable
  • Tea
  • Cosmetic
  • Glass
  • Plastic
  • Bakelite fit Resin
  • Mineral
  • Ceramic
  • Rare Earth Metallic Ore
  • Explosive item
  • Cattle Feed
  • Tobacco-Snuff
  • Wood chips
  • Coke and other many
Applications
  • Permissible Feed Size Up to 6.00 mm
  • Fineness Achievable Up to 40 mesh
  • Permissible Hardness Up to 3 MOH's scale
  • Permissible Brittleness Medium to High
  • Permissible Moisture Up to 3%
Standard Supply

Pin mill fitted with Feed Hooper, Set of Fixed Beater Plate, Set of Rotor Plate, Screen Drum with Screen, & ā€˜Vā€™ Pulley for Machine.
